HID FargoIn Stock
Card Imaging Fargo HDP6600 Dual sided 600 DPI ID Card Printer & Supplies Bundle Software 94640
About this item
- Retransfer (HDP) dye-sublimation and resin thermal transfer, prints over the edge
- 600 dpi (23.6 dots/mm) print resolution
- Single or dual-sided, via the dual-sided module
- Color print speed: Up to 230 cards/hour, 16 sec/card (YMCK with transfer); 126 cards/hour, 29 sec/card (YMCKK)
- Card capacity: 100-card input standard (200-card or dual hopper optional), 200-card output
- Connects by USB 2.0 and Ethernet 100 Mbps with internal print server, IPv4 and IPv6
Find it alongside the rest of our ID card printer range.
Own one already and it has stopped behaving? We handle printer repair and preventive maintenance.
Product description
About the Card Imaging Fargo HDP6600 Dual sided 600 DPI ID Card
The HDP6600 is a retransfer printer, which means it prints your design onto a clear film first and then fuses that film onto the card. The practical difference is that the image runs right over the edge with no white border, and cards with a chip or a slightly uneven surface still come out clean. It prints at 600 dpi, twice the resolution of a standard direct-to-card machine.
It is quick for what it is, at up to 230 cards an hour in full color. A SmartScreen OLED panel on the front tells you what the printer is doing without opening the software, and 1 GB of memory keeps longer batches moving. Card thickness from 30 to 40 mil is all in range, so it will take heavier access credentials as well as standard PVC.
The options cover what an ID office usually needs a year in: magnetic stripe encoding on all three tracks, contact and contactless encoding, and the LMX lamination module if your cards have to survive a few years on a lanyard. Security is built in rather than bolted on, with AES-256 encryption and resin scramble protection on the data sent to the printer. Printers bought on or after 1 August 2024 carry a four year warranty that includes a year of loaner coverage.
It runs the 84911 YMCK ribbon at 750 images and the 84900 clear film at 1,500, so you go through two ribbons for every roll of film. Order them in that ratio and you will not end up with a shelf of film and no ribbon.
It is quick for what it is, at up to 230 cards an hour in full color. A SmartScreen OLED panel on the front tells you what the printer is doing without opening the software, and 1 GB of memory keeps longer batches moving. Card thickness from 30 to 40 mil is all in range, so it will take heavier access credentials as well as standard PVC.
The options cover what an ID office usually needs a year in: magnetic stripe encoding on all three tracks, contact and contactless encoding, and the LMX lamination module if your cards have to survive a few years on a lanyard. Security is built in rather than bolted on, with AES-256 encryption and resin scramble protection on the data sent to the printer. Printers bought on or after 1 August 2024 carry a four year warranty that includes a year of loaner coverage.
It runs the 84911 YMCK ribbon at 750 images and the 84900 clear film at 1,500, so you go through two ribbons for every roll of film. Order them in that ratio and you will not end up with a shelf of film and no ribbon.
Specifications
Technical specifications
| Print method | Retransfer (HDP) dye-sublimation and resin thermal transfer, prints over the edge |
| Resolution | 600 dpi (23.6 dots/mm) |
| Colors | Up to 16.7 million, 256 shades per pixel |
| Print speed (color) | Up to 230 cards/hour, 16 sec/card (YMCK with transfer); 126 cards/hour, 29 sec/card (YMCKK) |
| Sides | Single or dual-sided, via the dual-sided module |
| Card size | CR-80 (3.375 x 2.125 in / 85.6 x 54 mm) |
| Card thickness | 30 mil to 40 mil (0.762 to 1.01 mm) |
| Card capacity | 100-card input standard (200-card or dual hopper optional), 200-card output |
| Memory | 1 GB RAM |
| Display | SmartScreen graphical OLED control panel |
| Connectivity | USB 2.0 and Ethernet 100 Mbps with internal print server, IPv4 and IPv6 |
| Encoding | Optional magnetic stripe (dual high and low coercivity, tracks 1, 2 and 3), contact and contactless smart card; reads HID Prox 125 kHz and iCLASS Standard, SE, SR and Seos |
| Lamination | Optional LMX card lamination module, one material or two material |
| Security | AES-256 data encryption and resin scramble data protection |
| Warranty | Four years on the printer for units bought on or after 1 August 2024, including a year of loaner support; lifetime printhead with unlimited card passes |
| Dimensions | 13.0 in H x 14.5 in W x 12.0 in D (330 x 368 x 305 mm) |
| Weight | 21.0 lb (9.5 kg) |
Ordering and returns
Price in USD. There is no checkout on this site. The Buy it Now button hands off to Amazon, and the price at Amazon checkout is the one that applies. Call us and we will confirm current pricing and take the order directly.
Stock items may be returned within 30 days of delivery. The customer is responsible for return shipping unless the error was ours. Orders completed at Amazon are governed by Amazon's returns policy, which applies to most orders placed from this page. Custom-programmed products are excluded. Full terms are on our terms page.
